- 6寸全頻喇叭
- 85鐵氧體磁鐵
- 25芯耐高溫音圈 ASV骨架
- 高強度的正邊鐵盆架配塑料壓圈
- 橡膠懸邊復合玻纖鼓紙 啞光PP子彈頭防塵帽
- 60Hz-7KHz頻響范圍
- 87dB靈敏度
- 80W額定功率
- 適用于書架音箱、中置音箱、主音箱
喇叭揚聲器
Aa1智泓 AT-25025
|
Nominal diameter:
|
6inch |
| Nominal impedance: | 7.2Ω |
| Power rating: | 15-80W |
| Sensitivity(1w\1m): | 87dB |
| Frequency range: | 60Hz-7KHz |
| Voice coil diameter: | 25 |
| Magnet dimension: | 80*40*20 |
| Fs: | 65.090Hz |
| Re: | 7.200 Ohm |
| Qms: | 2.810 |
| Qes: | 0.942 |
| Qts: | 0.705 |
| Vas: | 11.144 Ltr |
| Cms: | 445.485u M/N |
| n.(%): | 0.316 % |
| Bl: | 6.479 T |
| Sd: | 13.273K mm |
